The 4709ESII E-Type brake shoe kit is designed for heavy-duty truck front steer axle drum brake systems, providing reliable fit and consistent braking performance. Engineered for commercial and fleet replacement applications.

Specifications

• FMSI: 4709ESII
• GAWR: 23KFF
• Brake Shoe Width: 7 in
• Drum Diameter: 16.5  in
• Brake Shoe Type: E-Type
• Certification: FMVSS 121 Certified by LINK
• Replaces OEM #: 4709ESII
• New or Relined: New

Key Features

•         23K FF Rated Friction: Designed for 23,000 lbs GAWR applications with FF-rated linings to deliver smooth, predictable braking and thermal stability on front steer axles.
• FMVSS 121 Certified: Independently tested and validated by LINK Engineering to meet federal braking performance requirements for commercial vehicles.
• Precision E-Type S-Cam Fit: Engineered for 16.5" × 7" S-Cam drum brake systems, ensuring proper shoe alignment, even lining wear, and reliable service life on steer axles.
• Durable Steel Construction: Manufactured from high-strength steel with corrosion-resistant treatment to help prevent rust jacking and withstand harsh road and weather conditions.
• There are zero Core charges, you are not required to return your old cores for a hassle-free transaction!
